EC-100 Digital Coating Thickness Gauge Car Auto Paint Thickness Measurement


999 in stock

SKU: 32903056661 Category:


This gauge is ultra low cost coating thickness gauge and can mainly be used to measure paint coating thickness. It is used for non-destructive coating thickness measurement of non-magnetic coatings, e.g. paint, enamel, chrome on steel, and insulating coatings, e.g. paint and anodizing coatings on non-ferrous metals.

Model EC-100
Probe F-Probe & N-Probe
Measuring Principle Magnetic induction & Eddy Currents
Measuring Range 0 to 2000um
Accuracy ± (2%+0.02mm)
Resolution 0~499(1um) 500um~2000um(0.01mm)
Calibration zero point calibration
Units um , mm, mil
Maximum Measuring Rate Two readings per second
Power Supply Two 1.5V AAA battery
Operation Environment Temperature: -10 to 50°C
Storage Environment Temperature: -20 to 70°C
Dimensions 89mm*49mm*21mm
Case Material And Weight ABS

weight: 45 g

Ultra low cost
Easy to do zero calibration
Power off automatically
Low battery indication
Automatically detect the substrates type
Multi-point calibration open to user

car’s paint thickness testing
paint thickness testing

1pc Coating thickness gauge
1pc Aluminum Plate
5pcs Plastic Films(1pc 0.05mm, 1pc 0.1mm, 1pc 0.25mm, 1pc 0.5mm, 1pc 1mm)
1pc User Manual

1. WORLDWIDE SHIPPING. (Except some countries and APO/FPO)
2. Orders processed timely after the payment verification.
3. We only ship to confirmed order addresses. Your order address MUST MATCH your Shipping address.
4. The images shown are not the actual item and are for your reference only.
5. SERVICE TRANSIT TIME is provided by the carrier and excludes weekends and holidays. Transit time may vary, particularly during the holiday season.
6. If you have not received your orderafter 30 days from payment, please contact us. We will trace your order and get back to you asap. Our goal is customer satisfaction!
7. Delivery Time:

1. You have 7 days to contact us and 30 days to return it from the date received. If the item is in your possession more than 7 days, it will be considered used and WE WILL NOT ISSUEA REFUND OR REPLACEMENT to you. There are NO EXCEPTIONS!
Shipping cost is bear by both seller and buyer in half.
2. All returned items MUST BE in the original packaging and you MUST PROVIDE us with the shipping tracking number, specific reason for the return, and your order ID.
3. We will refund YOUR FULL WINNING BID AMOUNT, upon receipt of the item in its original condition and packaging with all components and accessories included, AFTER BOTH Buyer and Seller cancel the transaction from aliexpress. OR, you may choose to have a replacement.
4. We will bear all the shipping cost if the product(s) is (are) not as advertised.
1. 12 months Manufacturer’s limited Warranty for defective items (excluding items damaged and/or misused after receipt). Accessories come with a 3-month warranty.
2. Defective items MUST BE reported and returned within the warranty period (and in the original packaging, if possible). You must tell us what the defect is and give us your order number. WE DO NOT REPAIR OR REPLACE ITEMS WITH AN
You agree to all of the above-listed policies upon ordering on aliexpress!
We maintain high standards of excellence and strive for 100% customer satisfaction! Feedback is very important. We request that you contact us immediately BEFORE you give us neutral or negative feedback, so that we can perform up your satisfaction.
It is impossible to address issues if we do not know about them!

Additional information

Weight 0.12 kg
Dimensions 12 x 10 x 12 cm
Brand Name


Model Number

Coating thickness gauge

With Backlight Or Not



± (2%+0.02mm)


0~499(1um) 500um~2000um(0.01mm)

Measuring Range

0 to 2000um


F-Probe & N-Probe

Maximum Measuring Rate

Two readings per second





Operation Environment Temperature

-10 to 50°C

Storage Environment Temperature

-20 to 70°C
