2019 Original Mijia Aqara Wireless Relay Module Two-way Control Double Channels Switch Controller Smart Home For Xiaomi Mi Home

(10 customer reviews)


SKU: 33000423688 Categories: ,



Product: LLKZMK11LM

Product Size: 49.3*46*24mm

Wireless Connections: Zigbee

Input Voltage: 100-250V, 50Hz

Maximum Load: 10A/2500W

Operating Temperature: -10℃~+50℃

Working Humidity:5%~95%RH


This product must be used with a gateway and there must have a neutral line.

How to troubleshoot installation issues

1:Make sure the circuit come with neutral line .
2:”N” connect neutral line ,the second “IN” connect live line .Cause “L” and “IN” connect complete .
3:If the first time connect a wrong method ,because it is strong electricity , there will be burned mostly.
4:The original “L” and “IN” can not uninstall .
5:S1 and S2 can not connect the power directly ,must connect a short line come from “L” , best within 50cm.


Additional information

Weight 0.1 kg

wireless relay



Max Speed:

xiaomi aqara

Model Number:





xiaomi smart home

State of Assembly:


Brand Name:


Wireless connect:

ZigBee(an aqara hub is required)

Neutral line:



ZigBee Repeater


Xiaomi Aqara Two-way control module

10 reviews for 2019 Original Mijia Aqara Wireless Relay Module Two-way Control Double Channels Switch Controller Smart Home For Xiaomi Mi Home

  1. unknown

    It came quickly, the box is small, everything works.

  2. unknown

    very good seller good commnucation and fast shipping works under 220v 60hz
    no noise and no heat
    very good device

  3. unknown

    Very fast shipping!

  4. unknown

    Delivery is fast. unfortunately worked half a day and broke,

  5. unknown

    For now everything ok, without using it. It seems to comply with the described

  6. unknown

    excellent product fast shipping will buy from this store again thank you.

  7. unknown

    Got to st. petersburg in 20 days, everything works. Pulls on the control of ventilation in the bath and toilet

  8. unknown

    Original, everything is as it should be. The seller quickly sent, arrived very quickly. Well done!

  9. unknown

    Both relays burned by their fault. Connected to the relay phase from the switches. It is necessary to connect from the relay, ie physical switches are connected only to the relay! The relays themselves came a week before moscow

  10. unknown

    Of the minuses, the scenarios created in the michum are not worked out on the logical switch, other scenarios did not create, looks miserable when you connect to the lamp, inside did not fit even the device and not bulky. A blue solution.
    Otherwise everything is fine: shows the power, control possible 2 relays from the mihome.
    I recommend the seller, everything was made clearly coherent and beautiful, except for the packaging, changed))
